OM3 Fiber optic Patch cord LC/UPC to LC/UPC Duplex Aqua
P/N: PC32U2UD3L-1M
Packaging: Neutral or OEM service optional
MOQ: 1 Piece
Certificate: RoHS Compliant Material
Lead Time: 3 days
Payment Method: T/T, Western Union
Order Information:
PC32U2UD3L-1M OM3 Fiber optic Patch cord LC/UPC to LC/UPC Duplex Aqua 3.0mm LSZH 1meter
PC32U2UD3L-2M OM3 Fiber optic Patch cord LC/UPC to LC/UPC Duplex Aqua 3.0mm LSZH 2meter
PC32U2UD3L-3M OM3 Fiber optic Patch cord LC/UPC to LC/UPC Duplex Aqua 3.0mm LSZH 3meter
PC32U2UD3L-5M OM3 Fiber optic Patch cord LC/UPC to LC/UPC Duplex Aqua 3.0mm LSZH 5meter
PC32U2UD3L-10M OM3 Fiber optic Patch cord LC/UPC to LC/UPC Duplex Aqua 3.0mm LSZH 10meter
PC32U2UD3L-15M OM3 Fiber optic Patch cord LC/UPC to LC/UPC Duplex Aqua 3.0mm LSZH 15meter
Description:
Jacket : Aqua PVC/LSZH
Fiber: OM3 50/125µm
Connectors: 2x LC Aqua and 2x LC Aqua
Connectors: 2x LC Aqua and 2x LC Aqua
XX=length, any length is available upon your request
Other colors cable Jacket is available
Parameter:
| Item | SM | MM | |
| Polishing Type | UPC | APC | UPC |
| Insertion Loss | <=0.3dB | <0.3dB /0.5dB(MTRJ) | |
| Customize | |||
| Return Loss | >=55dB | >=60dB | / |
| Customize | |||
| Durability | <=0.2dB increase Max. | ||
| Operating Temperature | -20℃ to +75℃ | ||
| Storage Temperature | -40℃ to +75℃ | ||
Product Package:
Each patch cord is packaged individually and individually identified for traceability,
a test certification is supplied with each assembly.
We can provide custom packaging to your specification.
