Fiber Optic Patch Panel sliding type 4U 19” SC Port 144Cores LC 288cores with 12pcs Modules - PPS4
P/N: PPS4
Packaging: Neutral or OEM service optional
MOQ: 1 Piece
Certificate: RoHS Compliant Material
Lead Time: 3-7 days
Payment Method: T/T, Western Union
Fiber Optic Patch Panel sliding type 4U 19” SC Port 144Cores LC 288cores with 12pcs Modules
Features:
- 19’’ sliding-out type with tray plate , rack mounted
- High density
-The body is made of cold rolled steel sheet with electrostatic spraying (also could be aluminium).
- Thickness :1.5mm
- with 12pcs Modules to easy replace, Easy to maintain and extend
- available for the installation of FC,SC,ST,LC adapter
- Outline dimension : 484x349x178mm
- 4U, 144-288cores are available
- Max.capacity 288fibers
- Color : White or Black
Order Information:
P/N | Dimension (mm) | Adapter type | Port Qty | Max.Capacity (cores) |
PPS4-SC144 | 484x349x4U | SC simplex | 144 | 144 |
PPS4-LCD144 | 484x349x4U | LC duplex | 144 | 288 |
